Solar Pump Inverters 3HP 3phase DC 250V to DC 750V for normal motor
EM15-SP series solar inverter is high-efficiency solar water pump controller, which with high MPPT efficiency, green environmental protection, economic and energy saving, widely use for agricultural irrigation, water supply system and etc.
Products Feature:
Energy consumption
Energy Consumption Comparison :Use the traditional energy will cause pollution,and in the cost of rising trend,the use of clean energy has use cost and environmental cost advantages.
Maintenance costs
Use and maintenance:The solar energy system life for up to 25 years,and low failure rate , Automatic operation ,
Don't need someone to watch,Maintenance personnel can be divided into many groups to patrol.
- Support voltage and power range: Single phase or three phase 220V, Three phase 380V; Power is from 0.75kW to 400KW.
- Easy to use, built in water pump protection functions.
- The water level detection functions, which can support terminal /analog detection.
- PV power, PV current, pump flow rate and other operating parameters are accurately displayed.
EM15-SP3 Description | d75 | 1d5 | 2d2 | 004 | 5d5 | 7d5 | 011 | 015 | 018 | 022 | 030 | 037 | 045 |
| 055 | 075 | 090 | 110 | 132 | 160 | 200 | 220 | 250 | 280 | 315 | 355 | 400 |
| DC input (+, -) |
| Rated power/KW | 0.75 | 1.5 | 2.2 | 4 | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 45 |
| 55 | 75 | 90 | 110 | 132 | 160 | 200 | 220 | 250 | 280 | 315 | 355 | 400 |
| Min. DC voltage/V | 280 |
| Max.DC voltage/V | 750 |
| Recommended MPPT range /V | 350~750 |
| AC output(U, V, W) |
| Output current | 2.1 | 3.8 | 5.1 | 9 | 13 | 17 | 25 | 32 | 37 | 45 | 60 | 75 | 91 |
| 112 | 150 | 176 | 210 | 253 | 304 | 377 | 426 | 465 | 520 | 585 | 650 | 725 |
| Output frequency | 0~50/60Hz |
| Power factor | >0.99 |
| Communication mode | RS485 communication |
| Protection class | IP20 |
| Ambient temperature | -10℃~ +40℃(ambient temperation at 40℃~50℃,please keep derated use) |
| Storage temperature | -20℃~ +60℃ |
| Humidity | Smaller than 95%RH, non-condensation |
| Cooling | Forced Air cooling |
| Altitude | Lower than 1000 m |
| Humidity | Less than 95%RH, without condensing |
| Vibration | Less than 5.9 m/s2 (0.6 g) |
Q&A
Who are we?
We are based in Guangdong, China, start from 2017,sell to Domestic Market(50.00%),Southeast Asia(12.00%),Eastern Europe(12.00%),South America(5.00%),Eastern Asia(3.00%),Northern Europe(3.00%),Oceania(3.00%),Southern Europe(3.00%),North America(2.00%),Western Europe(2.00%),Mid East(2.00%),Africa(1.00%),South Asia(1.00%),Central America(1.00%). There are total about 51-100 people in our office.
How can we guarantee quality?
EMHEATER frequency inverter passed IEC test and has CE certificate. Each piece of VFD will have 4 testing before delivery, follow ISO 9001 standard. We offer high quality VFD.
Always a pre-production sample before mass production;
Always final Inspection before shipment;
